4. Main, vice clutch
1) Installment:
¡¤Clutch gear assy(secondary)
¡¤Spline washer ¢Ú
2) Installment:
¡¤Friction plate ¢Ù
¡¤Clutch plate ¢Ú(Install to clutch hub ¢Û)
Caution
Install the clutch plate and friction plate to the
clutch hub alternately, from friction plate to fric-
tion plate.
3) Installment:
¡¤Clutch hub ¢Ù
(Install to pressure plate ¢Ú)
Caution
The arrow mark ¢Ûof clutch hub should align
with the arrow mark ¢Üon the pressure plate.
4) Installment:
¡¤Clutch hub, pressure plate, clutch plate and
friction plate assy ¢Ù (to main shaft ¢Ú)
¡¤Locking washer ¢Û
¡¤Nut ¢Ü (clutch hub)
Caution
Be sure to use new locking
¡¤Be sure to install the locking washer inside
the indent of clutch hub.
5) Tighten up:
¡¤Nut ¢Ü(Clutch hub)
Caution
Fasten the clutch hub, then tighten up the nut.
¢Ù
¢Ú
¢Û
¢Ü
¢Ù
¢Ú
¢Û
¢Û
¢Ú
¢Ù
¢Ü
- 184 -
