6) Applying engine oil
¡¤4-stroke engine oil
(Apply the parts inside the oil pump)
7)Installment:
¡¤Oil pump seat ¢Ù
¡¤Outer rotor ¢Ú
¡¤Inner rotor ¢Û
¡¤Locating pin ¢Ü
¡¤Oil pump gear assy ¢Ý
¡¤Driving pin ¢Þ
¡¤Oil pump cover ¢ß
¡¤Screw ¢à
Applying engine oil
¡¤4-stroke engine oil
(Apply to the lubrication oil trace of crankcase)
The enough 4-stroke engine oil should be ap-
plied to lubrication oil trace of crankcase, oth-
erwise the engine would be damaged.
9)Applying engine oil
¡¤4-stroke engine oil
(Applying on the lubrication oil trace of oil pump)
10)Installment
¡¤Oil pump pad
¡¤Oil pump (to crankcase)
¡¤Tighten up screw
Caution
Caution
¡¤Be sure to use new pad
3. Right connecting case
1)Installment
¡¤Right connecting case gasket ¢Ù(new)
¡¤Locating pin ¢Ú
¡¤Right connecting case ¢Û
Caution
¡¤Be sure to use new gasket.
2) Tighten up
Screw (right connecting case).
¢Ù
¢Ú
¢Ù
7Nm
- 183 -
Apply lubrication oil
Apply lubrication oil
