2. Shift shaft and oil pump
1)Installment:
¡¤Star gear ¢Ù
¡¤Locating pin ¢Ú(long)
¡¤Shift pin ¢Û(short)
2) Installment:
¡¤Star gear (install to shift cam)
The hole of shift cam should be align with the
location pin ¢Ú (long) of star gear.
Caution
Install the location pin ¢Ú(long) to the filting mark
¢Ü position.
Caution
3) Tighten up :
¡¤Screw ¢Ù (Star gear)
¡¤Apply the thread fastening agent on the screw
¢Ù .
4) Installment
¡¤Shift torsion spring ¢Ù(install to shift shaft)
¡¤washer ¢Ú
¡¤Limit lever ¢Ûand limit torsion spring assy
¢Ü
¡¤washer ¢Ý
5) Installment
¡¤Shift shaft ¢Ù
¡¤Before installing the shift shaft, apply the
grease to the oil seal lip (left crankcase).
¡¤Pull the hook plate ¢Ú in arrow direction and
limit lever ¢Ûand press and install them to the
star gear
¡¤Make sure that the torsion spring pin ¢Üin
spring hook ¢Ü
Caution
¢Ù
¢Ú
¢Ù
12Nm
- 182 -
