ATV 200 - Page 197

7. Electric starting system
1)Mount
¡¤Timing chain ¢Ù
¡¤Up guide plate ¢Ú
Caution
Tight the shaft wire ¢Û of timing chain for
avoiding it is dropped into the crankcase.
Must use new washer
Caution
2) Mount
¡¤Washer ¢Ù
¡¤Electric starting gear assy ¢Ú
¡¤semicircle key ¢Û
¡¤Magneto rotor ¢Ü
Caution
¡¤Clean the conical part of crank and magneto
¡¤When installing the magneto the key must
be installed in to key groove of crank for avoid-
ing it.
¡¤Mount the magneto ¢Üdrops out on the
crank, and then fix the electric starting gear
assy ¢Úturn the magneto by counterclock-
wise to make it into the electric starting big
gear.
3) Mount:
¡¤Double wheel ¢Ù
¡¤Washer ¢Ú
¡¤Wheel axle¢Û
¡¤Locating pin ¢Ü
¡¤Sealing washer ¢Ý of left crankcase cover¢Ý
8Nm
¢Ú
¢Ù
¢Û
¢Ù
¢Ú
¢Û
¢Ú
¢Û
¢Ú
¢Ù
¢Ü
¢Ü
¢Ý
¢Ú
¢Ü
- 191 -
