7) Mount:
¡¤Output shaft ¢Ù
¡¤Connecting claw ¢Ú
¡¤Front splice ¢Û
¡¤Washer ¢Ü
¡¤Nut ¢Ý
¡¤Check every needle bearing because the needle
maybe drop out from bearing core to lose. If it
is like this the universal joint. Can’ t be turned
flexiblely.
¡¤Insert the needle bearing into universal joint
entirely to ensure the hog ring can be mounted.
Caution
8)Fasten
¡¤Nut ¢Ý
9)Mount
¡¤Rear joint and driving fork.
Mounting steps:
¡¤Mount the relative driving fork into the splice
¡¤Coat grease on the needle bearing
¡¤Press every needle bearing into the front splice
with proper tube to ensure that the driving fork
is inserted into the needle bearing hole.
¡¤Fix the hog ring into every bearing groove.
Caution
¡¤Fix the front splice ¢Ûwith universal joint
holder and connect the locking nut ¢Ý.
¡¤Apply the thread fastening agent on the nut
¢ÝWhen mounting it.
¢Ý
¢Ü
¢Û
¢Ú
¢Ù
¢Ù
- 190 -
