ATV 200 - Page 195

2. Output shaft assy
1) Mount
¡¤Bearing ¢Ù(to rear cover)
¡¤Nut collar ¢Ú
Caution
Use the nut collar spanner ¢Ûto tighten the
collar.
4) Fasten
¡¤Special-shaped left-handed nut
5) Mount:
¡¤Washer ¢Ù
¡¤Bearing ¢Ú
¡¤Nut collar ¢Û
Caution
¡¤Use hexagnal socket head screw wrench ¢Ü
¡¤Coat¡°518 anaerobic sealing gum¡± or equal
substitute on outer end surface of bearing ¢Ú
which side is near to washer.
¡¤Coat thread fastening agent on hexagnal
socket head screw nut collar ¢Û
6) Fasten
¡¤hexagnal socket head screw nut collar
3) Mount
Washer ¢Ù
¡¤Reverse gear ¢Ú
¡¤Compromise left-turning nut ¢Û
Caution
¡¤Fasten the compromise left-turning nut by
counter clockwise direction, because it is left-
turning thread.
¡¤Use special-shaped nut spanner ¢Ü
¢Û
¢Ú
¢Ù
¢Ü
¢Û
50Nm
¢Ù
¢Ú
¢Ù
¢Ú
¢Û
¢Ü
- 189 -
