6. Installtion of adjusting washer

1) Washer A

Mount

¡¤Washer A ¢Ù

¡¤Bearing ¢Ú

Mount:

¡¤Clamp plate ¢Ù

2) Washer B

Mount:

¡¤Forward gear

¡¤Washer B

¡¤Bearing

Caution

This step is carried out before assembly with

closing case.

This step is carried out before assembly with

case.

- 197 -
