6. Mount:
¡¤Cylinder ¢Ù
¡¤
Tighten bolt (cylinder) temporarily
¡¤When pressing the piston ring with one hand,
assembly the cylinder with another one.
¡¤The timing chain should through the bend-
ing locking end
¢Úof chain chamber.
Warning
¡¤Thread hole on the rocke shaft is toward out.
¡¤Mount short rocker shaft ¢Ù(With O-ring¢Ú),
at the side of outlet and the long rocker shaft
¢Û (with slot¢Ü at the side of inlet.)
¡¤The slot ¢Üdirection, need to be adjusted
when mounting inlet rocker shaft, to make the
slot align with hole of cylinder cover bolt
¢Ý
Caution
7. Lubricate:
¡¤Valve rocker ¢Ù
¡¤
Rocker shaft ¢Ú
¡¤
Lubrication oil: SAE 10W30 machine oil
8. Install
¡¤Valve rocker
¡¤Rocker shaft
¢Ù
¢Û
¢Ù
¢Ú
¢Ù
¢Ú
¢Ý
¢Û
¢Ü
- 200 -
