10. Mount:
¡¤Valve cam ¢Ù
Caution
11. Mount:
¡¤Clamp plate ¢Ù(Bearing)
¡¤Locking plate ¢Ú(new)
The driving pin¢Ú on the end of valve cam
must align to the timing mark ¢Ûon the cyl-
inder cover.
9. Mount:
¡¤Bearing ¢Ù(to valve cam)
¡¤Bearing ¢Ú(to valve cam)
Caution
The bearing ¢Ùwith oil sealing is toward out
when assembling it, and the bearing
¢Úwith
dust cap is toward inside when assembling
it.
12. Fasten
¡¤Bolt ¢Ù
13. Bend locking plate end¢Ú
¢Ù
¢Û
¢Ú
¢Û
¢Ú
¢Ù
¢Ù
¢Û
¢Ú
¢Ù
- 201 -
