¡¤Turn the crank until the mark TDC¢Û is cor-
respondence
with the mark on the crankcase
cover
¢Ü.
¡¤Mount the timing chain to the timing sprocket
pulley.
¡¤Mount the timing sprocket pulley to the cam
shaft for ensuring the mark of timing sprocket
pulley ¢Ý is correspondence with the mark ¢Ú
on the cylinder head, then fasten the sprocket
pulley bolt with hand.
(Be ensure the tension of the timing chain at
the outlet when mounting the timing
sprocket
pulley)
¡¤Insert the special tooling into the tension hole
of timing chain and pull the tensioner timing
chain toward inside.
¡¤The matching mark ¢Ýof timing sprocket is
sure to correspond to the matching mark
¢Ú of
cylinder head when pulling the timing chain
tensioner.
¡¤Change the matching position between
sprocket pulley and chain if the marks is not
aligned.
¡¤After the marks is aligned, fasten the bolt
of timing sprocket.
Fix the starting ratchet
¢Þand tighten the bolt
of timing
sprocket.
17. Mount:
Tensioner of timing chain
Mounting steps:
¡¤Take off bolt ¢Ùfrom the tensioner of tim-
ing chain.
Caution
¢Ú
¢Ý
¢Þ
60Nm
