Audi Q7 2007 !
6-cylinder TDI engine (3.0 ltr. 4-valve common rail), mechanics 01.2006
1 Removing and installing engine
5
6
♦ Scissor-type assembly platform -VAS 6131- with support
set for Audi -VAS 6131/10- and support set -VAS 6131/
11-, -VAS 6131/13- and 3x -VAS 6131/10-2-
♦ Drip tray for workshop hoist -VAS 6208-
Procedure
– Activate jacking-up mode on vehicles with air suspension
⇒ Rep. Gr. 43.
– Move driver's seat as far back as possible and to highest
position, using range of full seat adjustment.
– Switch off ignition.
– Reach under driver's seat and release retaining clips on rear
side of cover -1- in direction of -arrow A-.
– Then detach cover from driver's seat console in direction
of -arrow B-.
– Use removal lever -80-200- to pry out cover -1- from floor
covering.
– Lift floor covering -2- slightly around earth wire.
– Unscrew nut -3- and detach earth wire -4- from earth
point.
– Discharge the refrigerant system ⇒ Air conditioner system
- with refrigerant R134a.
– Extract hydraulic fluid for power steering from reservoir us-
ing used oil collection and extraction unit -V.A.G 1782-.
– Open filler cap on coolant expansion tank.
WARNING!
Hot steam or hot coolant can escape when expansion tank
is opened; cover filler cap with cloth and open carefully.
