Audi Q7 2007 !
6-cylinder TDI engine (3.0 ltr. 4-valve common rail), mechanics 01.2006
1 Servicing work on pulley end
41
6
Before removing, mark direction of rotation of poly V-belt with
chalk or felt-tipped pen. If the belt runs in the opposite direc-
tion when it is refitted, this can cause breakage.
– Slacken poly V-belt by swivelling tensioner in direction of
-arrow-, using a lever with TORX 60 bit.
– Remove poly V-belt from tensioning roller.
– Mark position of vibration damper for re-installation.
– Unscrew bolts -1- and remove vibration damper.
Installing
Installation is carried out in the reverse order; note the follow-
ing:
– Install poly V-belt ⇒ page 39.
Tightening torque
1.5 Renewing crankshaft oil seal (pulley end)
Special tools and workshop equipment required
♦ Oil seal extractor -T40019-
Component Nm
Vibration damper to crankshaft
27
1)
•
1)
Bolt strength rating 10.9
Note
