6-cylinder TDI engine (3.0 ltr. 4-valve common rail), mechanics 01.2006
1 Removing and installing parts of lubrication system
139
6
♦ Engine support bracket (supplementary set) -T40093-
♦ Electric drill with plastic brush attachment
♦ Safety goggles
♦ Sealant ⇒ Parts catalogue
Removing
– Remove poly V-belt ⇒ page 39.
– Remove poly V-belt tensioner ⇒ page 40.
– Remove coolant pipe (left-side) ⇒ page 174.
– Remove air cleaner housing ⇒ Rep. Gr. 23.
– Remove nuts for engine mountings -arrow- on both sides.
– Remove front left wheel housing liner ⇒ Rep. Gr. 66.
– Unscrew nuts and bolts -arrows- for retaining clips for re-
frigerant line.
When the clips have been loosened, the refrigerant lines can
be moved slightly to one side in order to position supports
-10-222 A/19- onto longitudinal members.
– Set up support bracket -10-222 A- with connecting pieces
-T40091/3- and 2 spindles on wing panel flanges.
• The spindles face forwards.
– Attach both spindles to both rear engine lifting eyes.
Note
