6-cylinder TDI engine (3.0 ltr. 4-valve common rail), mechanics 01.2006
1 Removing and installing parts of lubrication system
151
6
Removing
– Carefully pull engine cover panel off four retaining pins one
after the other -arrows-.
– Unscrew union nuts -1 ... 4- and detach high-pressure
pipes.
– Remove intake manifold (top section) ⇒ Rep. Gr. 23.
– Loosen sealing cap -arrow- using 32 mm socket. Take off
sealing cap together with oil filter element.
– Pull oil filter element off sealing cap.
– Disconnect oil supply pipe -arrow- from mounting plate.
