Audi Q7 2007 !
6-cylinder TDI engine (3.0 ltr. 4-valve common rail), mechanics 01.2006
Repair Group 10 – Removing and installing engine
6
20
– Position the support elements from -VAS 6131/10- at left
and right of gearbox carrier, as shown in the illustration.
– Turn spindles for the support elements upwards until all lo-
cating lugs make contact with the mounting points.
– Tighten base plates for support elements to 20 Nm on scis-
sor-type assembly platform -VAS 6131-.
– Disengage both spring tensioners -VW 552- from drillings
in wheel housing.
– Mark the installation position of the subframe, the engine
cross member and the gearbox carrier on longitudinal
members with felt-tip pen.
– Unscrew bolts -1 ... 4- in diagonal sequence and in stages.
♦ Check that all hoses and other connections between en-
gine/gearbox assembly and body have been detached.
♦ Carefully guide out engine/gearbox assembly from engine
compartment when lowering to avoid damage.
♦ Carefully guide suspension struts past longitudinal mem-
bers.
– Lower the engine/gearbox assembly using scissor-type as-
sembly platform -VAS 6131- initially only as far as dis-
tance -a-.
• Dimension -a- = 200 mm.
Note
