445HD IP Phone
User's Manual 112 Document #: LTRT-14840
Figure 8-22: Popup Menu: 'Disconnect' Enabled, 'Phone Pairing' Disabled
7. After selecting the Disconnect menu option, the 'AC BToE Disconnected' indication is
displayed:
Figure 8-23: BToE Disconnected
8. From the popup menu as well you can see if BToE is disconnected:
Figure 8-24: Popup Menu: BToE Disconnected
Note: When BToE is connected, you can select the Phone Web menu option to open the
phone's the Web interface.
9. Use the table below as reference when determining BToE's connection state from the
taskbar icon.
Taskbar Icon BToE's connection state
BToE is connected
BToE is disconnected
BToE is connected but a failure is preventing a correct connection. The failure can be a
network problem or the wrong pair code was defined.
10. From the click popup menu, you can select the Exit option; the BToE PC application stops.
You can activate the application again from the Start menu as shown in Figure 8-25.
