AudioCodes MediaPack Series MP-11x

Version 6.6 123 MP-11x & MP-124
User's Manual 11. Network
11.6.2 Configuring the Internal SRV Table
The Internal SRV Table page resolves host names to DNS A-Records. Three different A-
Records can be assigned to each host name, where each A-Record contains the host
name, priority, weight, and port.
Notes:
• If the Internal SRV table is configured, the device initially attempts to
resolve a domain name using this table. If the domain name isn't found,
the device performs a Service Record (SRV) resolution using an external
DNS server configured in the Multiple Interface table (see 'Configuring IP
Network Interfaces' on page 105).
• The Internal SRV table can also be configured using the table ini file
parameter, SRV2IP (see 'DNS Parameters' on page 468).
 To configure the Internal SRV table:
1. Open the Internal SRV Table page (Configuration tab > VoIP menu > Network
submenu > DNS submenu > Internal SRV Table).
2. Click Add; the following dialog box appears:
Figure 11-8: Internal SRV Table Page
3. Configure the SRV rule, as required. For a description of the parameters, see the table
below.
4. Click Submit; the SRV rule is added to the table.
