44 DSP Templates
This section lists the DSP templates supported by the device. Each DSP template provides
support for specific voice coders (as well as channel capacity and various features).
Notes:
• To select the DSP Template that you want to use on the device, see
Configuring DSP Templates on page 160.
• Installation and use of voice coders is subject to obtaining the
appropriate license and royalty payments.
• The number of channels refers to the maximum channel capacity of the
device.
• For additional DSP templates, contact your AudioCodes representative.
Table 44-1: DSP Firmware Templates for MediaPack Series
DSP Template
0 1
Maximum Number of Channels
Default SRTP Enabled Default SRTP Enabled
MP-112 FXS/FXO
2 2 2 2
MP-114 FXS/FXO
4 3 3 3
MP-118 FXS/FXO
8 6 6 6
MP-124
24 18 18 18
Voice Coder
G.711 A/Mu-law PCM
Yes Yes
G.726 ADPCM
Yes Yes
G.727 ADPCM
Yes Yes
G.723.1
Yes Yes
G.729 A, B
Yes Yes
EG.711
Yes -
G.722
- Yes
