User's Manual 218 Document #: LTRT-65417
MP-11x & MP-124
Parameter Description
Web: Prefix to Add
EMS: Prefix/Suffix To Add
Defines the number or string to add at the front of the calling name. For
example, if you enter ITSP and the calling name is "company:name",
the new name is ITSPcompany:john".
Web: Suffix to Add
EMS: Prefix/Suffix To Add
Defines the number or string to add at the end of the calling name. For
example, if you enter 00 and calling name is "company:name", the new
name is "company:name00".
21.5 Configuring Redirect Number IP to Tel
You can configure rules for manipulating the redirect number received in the incoming
message:
Tel-to-IP redirect number manipulation: You can manipulate the prefix of the redirect
number, received from the Tel side, in the outgoing SIP Diversion, Resource-Priority,
or History-Info headers sent to the IP side. This is configured in the Redirect Number
Tel > IP table.
The redirect number manipulation tables provide two configuration areas:
Matching characteristics (Rule) of incoming call, for example, prefix of redirect
number.
Manipulation operation (Action), for example, remove user-defined number of digits
from the left of the redirect number.
If the incoming call matches the characteristics of a rule, then its manipulation action is
applied.
Notes:
• If the device copies the received destination number to the outgoing SIP
redirect number (enabled by the CopyDest2RedirectNumber parameter),
then no redirect number Tel-to-IP manipulation is done.
• The manipulation rules are done in the following order: Stripped Digits
From Left, Stripped Digits From Right, Number of Digits to Leave, Prefix
to Add, and then Suffix to Add.
• The Redirect Prefix parameter is used before it is manipulated.
• The redirect number manipulation tables can also be configured using
the ini file: Redirect Number Tel to IP table - RedirectNumberMapTel2Ip
(ini)
