Parameter Name Description
Operational Mode
[IPsecSATable_IPsecMode]
Defines the IPSec mode of operation.
 [0] Transport (default)
 [1] Tunnel
Remote Endpoint Addr
[IPsecSATable_RemoteEndpointAd
dressOrName]
Defines the IP address or DNS host name of the peer.
Note: This parameter is applicable only if the Operational
Mode is set to Transport.
Authentication Method
[IPsecSATable_AuthenticationMeth
od]
Defines the method for peer authentication during IKE main
mode.
 [0] Pre-shared Key (default)
 [1] RSA Signature = in X.509 certificate
Note: For RSA-based authentication, both peers must be
provisioned with certificates signed by a common CA. For
more information on certificates, see 'Replacing the Device's
Certificate' on page 93.
Shared Key
[IPsecSATable_SharedKey]
Defines the pre-shared key (in textual format). Both peers
must use the same pre-shared key for the authentication
process to succeed.
Notes:
 This parameter is applicable only if the Authentication
Method parameter is set to pre-shared key.
 The pre-shared key forms the basis of IPSec security and
therefore, it should be handled with care (the same as
sensitive passwords). It is not recommended to use the
same pre-shared key for several connections.
 Since the ini file is plain text, loading it to the device over
a secure network connection is recommended. Use a
secure transport such as HTTPS, or a direct crossed-
cable connection from a management PC.
 After it is configured, the value of the pre-shared key
cannot be retrieved.
Source Port
[IPsecSATable_SourcePort]
Defines the source port to which this configuration applies.
The default value is 0 (i.e., any port).
Destination Port
[IPsecSATable_DestPort]
Defines the destination port to which this configuration
applies.
The default value is 0 (i.e., any port).
Protocol
[IPsecSATable_Protocol]
Defines the protocol type to which this configuration applies.
Standard IP protocol numbers, as defined by the Internet
Assigned Numbers Authority (IANA) should be used, for
example:
 0 = Any protocol (default)
 17 = UDP
 6 = TCP
IKE SA Lifetime
[IPsecSATable_Phase1SaLifetimeIn
Sec]
Defines the duration (in seconds) for which the negotiated
IKE SA (Main mode) is valid. After this time expires, the SA
is re-negotiated.
The default value is 0 (i.e., unlimited).
Note: Main mode negotiation is a processor-intensive
