Version 6.6 189 MP-11x & MP-124

User's Manual 17. SIP Definitions

Parameter Description

Body List Type

[MessagePolicy_BodyListType]

Determines the policy for the defined SIP body.

 [0] Policy Blacklist =The specified SIP body (in the

'Body List' field) is rejected by the policy.

 [1] Policy Whitelist = (Default) The specified SIP body

(in the 'Body List' field) is allowed by the policy.

Default Chapter3
