AudioCodes MediaPack Series MP-11x

Version 6.6 385 MP-11x & MP-124
User's Manual 37. Syslog and Debug Recordings
 To configure logging filtering rules:
1. Open the Logging Filters Table page (Configuration tab > System menu > Logging
> Logging Filters Table).
2. Click the Add button; the Add Record dialog box appears:
Figure 37-2: Logging Filters Table - Add Record Dialog Box
3. Configure the logging filter, as required. See the table below for a description of the
parameters.
4. Click Submit to save your changes.
Notes:
• To configure the Syslog debug level, use the 'Debug Level' parameter
(see 'Configuring Syslog' on page 383).
• The Logging Filters table can also be configured using the table ini file
parameter, LoggingFilters.
Table 37-5: Logging Filters Table Parameters Description
Parameter Description
Type
[LoggingFilters_Type]
Defines the filter criteria.
 [1] Any (Default)
 [3] Trunk Group ID
 [5] FXS or FXO
 [6] Tel to IP = Specific Tel-to-IP routing rule listed in the
Outbound IP Routing table.
 [7] IP to Tel = Specific IP-to-Tel routing rule listed in the
Inbound IP Routing table.
 [8] IP Group
 [12] User = Specific user, defined by username or user@host.
Value
[LoggingFilters_Value]
Defines the value of the selected filtering type. This can be a single
value, a range separated by a dash or comma, or 'Any' (except for
Trunks and FXO/FXS which can be module/port or port).
Syslog
[LoggingFilters_Syslog]
Enables Syslog messages for the defined logging filter:
 [0] Disable (default)
 [1] Enable
