use the parameter ProxyDNSQueryType.
Web: Proxy DNS Query Type
[ProxyDNSQueryType]
Enables the use of DNS Naming Authority Pointer (NAPTR)
and Service Record (SRV) queries to discover Proxy servers.
 [0] A-Record (default)
 [1] SRV
 [2] NAPTR
If set to A-Record [0], no NAPTR or SRV queries are
performed.
If set to SRV [1] and the Proxy IP address parameter contains
a domain name without port definition (e.g., ProxyIP =
domain.com), an SRV query is performed. The SRV query
returns up to four Proxy host names and their weights. The
device then performs DNS A-record queries for each Proxy
host name (according to the received weights) to locate up to
four Proxy IP addresses. Therefore, if the first SRV query
returns two domain names and the A-record queries return two
IP addresses each, no additional searches are performed.
If set to NAPTR [2], an NAPTR query is performed. If it is
successful, an SRV query is sent according to the information
received in the NAPTR response. If the NAPTR query fails, an
SRV query is performed according to the configured transport
type.
If the Proxy IP address parameter contains a domain name
with port definition (e.g., ProxyIP = domain.com:5080), the
device performs a regular DNS A-record query.
If a specific Transport Type is defined, a NAPTR query is not
performed.
Note: When enabled, NAPTR/SRV queries are used to
discover Proxy servers even if the parameter DNSQueryType
is disabled.
Web/EMS: Use Gateway Name for
OPTIONS
[UseGatewayNameForOptions]
Determines whether the device uses its IP address or gateway
name in keep-alive SIP OPTIONS messages.
 [0] No = (Default) Use the device's IP address in keep-alive
OPTIONS messages.
 [1] Yes = Use 'Gateway Name' (SIPGatewayName) in
keep-alive OPTIONS messages.
The OPTIONS Request-URI host part contains either the
device's IP address or a string defined by the parameter
SIPGatewayName. The device uses the OPTIONS request as
a keep-alive message to its primary and redundant Proxies
(i.e., the parameter EnableProxyKeepAlive is set to 1).
Web/EMS: User Name
[UserName]
Defines the user name used for registration and Basic/Digest
authentication with a Proxy/Registrar server.
The default value is an empty string.
Notes:
 This parameter is applicable only if single device
registration is used (i.e., the parameter AuthenticationMode
is set to authentication per gateway).
 Instead of configuring this parameter, the Authentication
table can be used (see Authentication on page 265).
