Note: For this parameter to take effect, a device reset is
required.
Web: Silence Detection Method
[FarEndDisconnectSilenceMethod]
Determines the silence detection method.
ï‚§ [0] None = Silence detection option is disabled.
ï‚§ [1] Packets Count = According to packet count.
ï‚§ [2] Voice/Energy Detectors = (Default) According to
energy and voice detectors.
ï‚§ [3] All = According to packet count, and energy and
voice detectors.
Note: For this parameter to take effect, a device reset is
required.
[FarEndDisconnectSilenceThreshold]
Defines the threshold of the packet count (in percentages)
below which is considered silence by the device.
The valid range is 1 to 100%. The default is 8%.
Notes:
ï‚§ This parameter is applicable only if silence is detected
according to packet count
(FarEndDisconnectSilenceMethod is set to 1).
ï‚§ For this parameter to take effect, a device reset is
required.
[BrokenConnectionDuringSilence]
Enables the generation of the BrokenConnection event
during a silence period if the channel’s NoOp feature is
enabled (using the parameter NoOpEnable) and if the
channel stops receiving NoOp RTP packets.
ï‚§ [0] Disable (default)
ï‚§ [1] Enable
Web: Disconnect Call on Busy Tone
Detection
EMS: Disconnect On Detection End
Tones
[DisconnectOnBusyTone]
Determines whether a call is disconnected upon detection
of a busy tone.
ï‚§ [0] Disable = Call is not disconnected upon detection of
a busy tone.
ï‚§ [1] Enable = (Default) Call is released upon detection of
busy or reorder (fast busy) tone.
Notes:
ï‚§ This parameter is applicable only to FXO interfaces.
ï‚§ This parameter can also be configured in a Tel Profile.
Polarity (Current) Reversal for Call Release (Analog Interfaces) Parameters
[SetDefaultLinePolarityState]
Defines the FXO line polarity, required for DID signaling.
ï‚§ [0] = Positive line polarity
ï‚§ [1] = Negative line polarity
ï‚§ [2] = (Default) Auto - The device detects the polarity
upon power-up or upon insertion of the RJ-11 cable,
and uses it as a reference polarity.
Typically, if the RJ-11 cabling is connected correctly
(without crossing, Tip to Tip, Ring to Ring), the Tip line is
positive compared to the Ring line. In this case, set this
parameter to 0. With this configuration, the device
assumes that the idle line polarity is Tip line positive.
