PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Bit Configuration of D2013: ALM_L2 (Loop-2 alarm-1 to alarm-8 status)
Bit Symbol Event
0 ALM1_L2 ‘1’ when Loop-2 alarm 1 is ON; ‘0’ when OFF
1 ALM2_L2 ‘1’ when Loop-2 alarm 2 is ON; ‘0’ when OFF
2 ALM3_L2 ‘1’ when Loop-2 alarm 3 is ON; ‘0’ when OFF
3
4 ALM4_L2 ‘1’ when Loop-2 alarm 4 is ON; ‘0’ when OFF
5 ALM5_L2 ‘1’ when Loop-2 alarm 5 is ON; ‘0’ when OFF
6 ALM6_L2 ‘1’ when Loop-2 alarm 6 is ON; ‘0’ when OFF
7
8 ALM7_L2 ‘1’ when Loop-2 alarm 7 is ON; ‘0’ when OFF
9 ALM8_L2 ‘1’ when Loop-2 alarm 7 is ON; ‘0’ when OFF
10 to 15
