23-12
PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Bit Configuration of D2037: ALO_L1 (Loop-1 alarm-1 to alarm-8 output status)
Bit Symbol Event
0 ALO1_L1
Output status where Loop-1 alarm output 1 is assighed.
1:
1 ALO2_L1
Output status where Loop-1 alarm output 2 is assighed.
For bit information, same as bit 0.
2 ALO3_L1
Output status where Loop-1 alarm output 3 is assighed.
For bit information, same as bit 0.
3
4 ALO4_L1
Output status where Loop-1 alarm output 4 is assighed.
For bit information, same as bit 0.
5 ALO5_L1
Output status where Loop-1 alarm output 5 is assighed.
For bit information, same as bit 0.
6 ALO6_L1
Output status where Loop-1 alarm output 6 is assighed.
For bit information, same as bit 0.
7
8 ALO7_L1
Output status where Loop-1 alarm output 7 is assighed.
For bit information, same as bit 0.
9 ALO8_L1
Output status where Loop-1 alarm output 8 is assighed.
For bit information, same as bit 0.
10 to 15
Bit Configuration of D2038: ALO_L2 (Loop-2 alarm-1 to alarm-8 output status)
Bit Symbol Event
0 ALO1_L2
Output status where Loop-2 alarm output 1 is assighed.
1 ALO2_L2
Output status where Loop-2 alarm output 2 is assighed.
For bit information, same as bit 0.
2 ALO3_L2
Output status where Loop-2 alarm output 3 is assighed.
For bit information, same as bit 0.
3
4 ALO4_L2
Output status where Loop-2 alarm output 4 is assighed.
For bit information, same as bit 0.
5 ALO5_L2
Output status where Loop-2 alarm output 5 is assighed.
For bit information, same as bit 0.
6 ALO6_L2
Output status where Loop-2 alarm output 6 is assighed.
For bit information, same as bit 0.
7
8 ALO7_L2
Output status where Loop-2 alarm output 7 is assighed.
For bit information, same as bit 0.
9 ALO8_L2
Output status where Loop-2 alarm output 8 is assighed.
For bit information, same as bit 0.
10 to 15
