Automationdirect.com prosense PPC5 Series - Page 449

23-14
PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)

Bit Configuration of D2072: ALOLA1_L2 (Loop-2 alarm-1 to alarm-8 latch output status )
Bit Symbol Event
0 ALO1LA1_L2 Alarm-1 latch-1 output status
1 ALO2LA1_L2 Alarm-2 latch-1 output status
2 ALO3LA1_L2 Alarm-3 latch-1 output status
3
4 ALO4LA1_L2 Alarm-4 latch-1 output status
5 ALO5LA1_L2 Alarm-5 latch-1 output status
6 ALO6LA1_L2 Alarm-6 latch-1 output status
7
8 ALO7LA1_L2 Alarm-7 latch-1 output status
9 ALO8LA1_L2 Alarm-8 latch-1 output status
10 to 15

Bit Configuration of D2073: ALOLA2_L1 (Loop-1 alarm-1 to alarm-8 latch-2
output status)
Bit Symbol Event
0 ALO1LA2_L1 Alarm-1 latch-2 output status
1 ALO2LA2_L1 Alarm-2 latch-2 output status
2 ALO3LA2_L1 Alarm-3 latch-2 output status
3
4 ALO4LA2_L1 Alarm-4 latch-2 output status
5 ALO5LA2_L1 Alarm-5 latch-2 output status
6 ALO6LA2_L1 Alarm-6 latch-2 output status
7
8 ALO7LA2_L1 Alarm-7 latch-2 output status
9 ALO8LA2_L1 Alarm-8 latch-2 output status
10 to 15

Bit Configuration of D2074: ALOLA2_L2 (Loop-2 alarm-1 to alarm-8 latch-2
output status)
Bit Symbol Event
0 ALO1LA2_L2 Alarm-1 latch-2 output status
1 ALO2LA2_L2 Alarm-2 latch-2 output status
2 ALO3LA2_L2 Alarm-3 latch-2 output status
3
4 ALO4LA2_L2 Alarm-4 latch-2 output status
5 ALO5LA2_L2 Alarm-5 latch-2 output status
6 ALO6LA2_L2 Alarm-6 latch-2 output status
7
8 ALO7LA2_L2 Alarm-7 latch-2 output status
9 ALO8LA2_L2 Alarm-8 latch-2 output status
10 to 15

Bit Configuration of D2075: ALOLA3_L1 (Loop-1 alarm-1 to alarm-8 latch-3
output status)
Bit Symbol Event
0 ALO1LA3_L1 Alarm-1 latch-3 output status
1 ALO2LA3_L1 Alarm-2 latch-3 output status
2 ALO3LA3_L1 Alarm-3 latch-3 output status
3
4 ALO4LA3_L1 Alarm-4 latch-3 output status
5 ALO5LA3_L1 Alarm-5 latch-3 output status
6 ALO6LA3_L1 Alarm-6 latch-3 output status
7
8 ALO7LA3_L1 Alarm-7 latch-3 output status
9 ALO8LA3_L1 Alarm-8 latch-3 output status
10 to 15
