Chapter 23: D Registers (Holding Registers)
Loop-2 operation parameter
SP and alarm setpoint setting (Menu: SP)
D-Reg
No.
Ref.
No.
H No.
Register
symbol
R/W
D-Reg
No.
Ref.
No.
H No.
Register
symbol
R/W
D3701 43701 0E74
SP_L2_6
R/W D3751 43751 0EA6
A8_L2_8
R/W
D3702 43702 0E75 D3752 43752 0EA7
D3703 43703 0E76
PIDN_L2_6
R/W
D3704 43704 0E77
A1_L2_6
R/W
D3705 43705 0E78
A2_L2_6
R/W
D3706 43706 0E79
A3_L2_6
R/W
D3707 43707 0E7A
A4_L2_6
R/W
D3708 43708 0E7B
A5_L2_6
R/W
D3709 43709 0E7C
A6_L2_6
R/W
D3710 43710 0E7D
A7_L2_6
R/W
D3711 43711 0E7E
A8_L2_6
R/W
D3712 43712 0E7F
D3721 43721 0E88
SP_L2_7
R/W
D3722 43722 0E89
D3723 43723 0E8A
PIDN_L2_7
R/W
D3724 43724 0E8B
A1_L2_7
R/W
D3725 43725 0E8C
A2_L2_7
R/W
D3726 43726 0E8D
A3_L2_7
R/W
D3727 43727 0E8E
A4_L2_7
R/W
D3728 43728 0E8F
A5_L2_7
R/W
D3729 43729 0E90
A6_L2_7
R/W
D3730 43730 0E91
A7_L2_7
R/W
D3731 43731 0E92
A8_L2_7
R/W
D3732 43732 0E93
D3741 43741 0E9C
SP_L2_8
R/W
D3742 43742 0E9D
D3743 43743 0E9E
PIDN_L2_8
R/W
D3744 43744 0E9F
A1_L2_8
R/W
D3745 43745 0EA0
A2_L2_8
R/W
D3746 43746 0EA1
A3_L2_8
R/W
D3747 43747 0EA2
A4_L2_8
R/W
D3748 43748 0EA3
A5_L2_8
R/W
D3749 43749 0EA4
A6_L2_8
R/W
D3750 43750 0EA5
A7_L2_8
R/W
