2-9
PPC Manual Revision 1
Chapter 2 Introduction to Unit, Key, and Display Functions
No. in gure Name Description
PV display
(white or red)
Group display
(green)
Symbol display
(orange)
Data display (orange)
Bar-graph display
(orange and white)
Event indicator
(orange)
Key navigation
indicator
(green)
Parameter display
level indicator
(green)
Parameter display level EASY PRO
Deviation indicator
(green)
Status indicator
(green and red)
Display Description
Security indicator (red)
Ladder
Loop 2 indicator
(LP2 lamp)
(green)
To Next Page
