PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Register
No.
Description Range and meaning of value
D
5739
PV.D
PV display area ON/OFF
D5740
SP.D
Setpoint display area ON/OFF
D5741
STS.D
Status display area ON/OFF
D5742
SPD
Scroll speed (
D5743
GUID
Guide display ON/OFF
0
D5744
HOME
Home Operation Display setting
0
6: M
8
19: CS2 (S
D5745
ECO
Economy mode
0
1: E
2
D5746
BRI
Brightness (
D5747
B.PVW
White brightness adjustment of PV
display
Adjusts the white brightness of PV display.
D5748
B.PVR
Red brightness adjustment of PV
display
Adjusts the red brightness of PV display.
4 to 4
D5749
B.SP
Brightness adjustment of Setpoint
display
Adjusts the brightness of SP display.
4 to 4
D5750
B.BAR
Brightness adjustment of Bar-graph
display
Adjusts the brightness of SP display.
4 to 4
D5751
B.STS
Brightness adjustment of Status
indicator
Adjusts the brightness of Status display.
4 to 4
D5752
D5753
D.CYC
Display update cycle
1: 100 ms
2: 200 ms
3: 500 ms
4: 1 s
5: 2 s
D5754
OP.JP
AUTORETURN TO OPERATION
DISPLAY
Automatically returned to the Operation Display when
there has been no keystroke operation for 5 minutes.
D5755
MLSD
display
0
