Chapter 23: D Registers (Holding Registers)
Register
No.
Description Range and meaning of value
D5942
SP.B0
Bit-0 of SP number
Set an I relay number of contact input.

Standard terminals
DI1: 5025, DI2: 5026, DI3: 5027
E1-terminal area
DI16: 5046
D5943
SP.B1
Bit-1 of SP number
D5944
SP.B2
Bit-2 of SP number
D5945
SP.B3
Bit-3 of SP number
D5946
D5947
PN.BC
Bit changing method of PID number Same as D5941
D5948
PN.B0
Bit-0 of PID number
Same as D5942
D5949
PN.B1
Bit-1 of PID number
D5950
PN.B2
Bit-2 of PID number
D5951
PN.B3
Bit-3 of PID number
D5953
D5960
MP.BC_L1
Bit changing method of manual preset
output number
Same as D5941
D5961
MP.B0_L1
Bit-0 of manual preset output number
Same as D5942D5962
MP.B1_L1
Bit-1 of manual preset output number
D5963
MP.B2_L1
Bit-2 of manual preset output number
D5964
D5965
MP.BC_L2
Bit changing method of manual preset
output number
Same as D5941
D5966
MP.B0_L2
Bit-0 of manual preset output number
Same as D5942D5967
MP.B1_L2
Bit-1 of manual preset output number
D5968
MP.B2_L2
Bit-2 of manual preset output number
D5969 to D6000
D6001 MSG1
Messege-1 *2
20-digit value of alphanumeric characters can be
set.
Arrangement:
D6001, D6002, D6003, D6004, D6005, D6006,
D6007, DD6008, D6009, D6010, D6011
Write “0x00” to the register after the character
string.
D6002 MSG1
D6003 MSG1
D6004 MSG1
D6005 MSG1
D6006 MSG1
D6007 MSG1
D6008 MSG1
D6009 MSG1
D6010 MSG1
D6011 MSG1
D6012 to D6020
*2: With regards to the information on D6001 to D6011, D6021 to D6031, D6041 to D6051, and
D6061 to D6071, 11 D registers comprise one message.
