PPC Manual Revision 1
Chapter 23: D Registers (Holding Registers)
Constant register
D-Reg No. Ref. No. H No. Register symbol R/W
D7410 47410 1CF1 C_1 R
D7411 47411 1CF2 C0 R
D7412 47412 1CF3 C1 R
D7413 47413 1CF4 C2 R
D7414 47414 1CF5 C3 R
D7415 47415 1CF6 C4 R
D7416 47416 1CF7 C5 R
D7417 47417 1CF8 C10 R
D7418 47418 1CF9 C50 R
D7419 47419 1CFA C60 R
D7420 47420 1CFB C100 R
D7421 47421 1CFC C1000 R
D7422 47422 1CFD C10000 R
Input range / scale
D-Reg No. Ref. No. H No. Register symbol R/W
D7501 47501 1D4C DP_R R
D7502 47502 1D4D RH_R R
D7503 47503 1D4E RL_R R
D7504 47504 1D4F
D7505 47505 1D50 SDP_R R
D7506 47506 1D51 SH_R R
D7507 47507 1D52 SL_R R
D7508 47508 1D53
D7509 47509 1D54 DP_E1_R R
D7510 47510 1D55 RH_E1_R R
D7511 47511 1D56 RL_E1_R R
D7512 47512 1D57
D7513 47513 1D58 SDP_E1_R R
D7514 47514 1D59 SH_E1_R R
D7515 47515 1D5A SL_E1_R R
D7516 47516 1D5B
D7517 47517 1D5C DP_E2_R R
D7518 47518 1D5D RH_E2_R R
D7519 47519 1D5E RL_E2_R R
D7520 47520 1D5F
D7521 47521 1D60 SDP_E2_R R
D7522 47522 1D61 SH_E2_R R
D7523 47523 1D62 SL_E2_R R
D7524 47524 1D63
D7525 47525 1D64 DP_E4_R R
D7526 47526 1D65 RH_E4_R R
D7527 47527 1D66 RL_E4_R R
D7528 47528 1D67
D7529 47529 1D68 SDP_E4_R R
D7530 47530 1D69 SH_E4_R R
D7531 47531 1D6A SL_E4_R R
D7532 47532 1D6B
D7533 47533 1D6C P.DP_L1_R R
D7534 47534 1D6D P.RH_L1_R R
D7535 47535 1D6E P.RL_L1_R R
D7536 47536 1D6F
D7537 47537 1D70 P.DP_L2_R R
D7538 47538 1D71 P.RH_L2_R R
D7539 47539 1D72 P.RL_L2_R R
To Next Page
