Chapter 24: I Relays (Coil)
Example :
PVBO_L1
Indicates Loop-1 PVBO.
ADERR_E1
Indicates ADERR in E1-terminal area.
System error Input error
NO. I relay symbol R/W NO. I relay symbol R/W
4001
SYSTEM_ERR
R
4065
ADERR R
4002
CALB_ERR
R
4066
ADERR_E1 R
4003
UPARA_ERR
R
4067
ADERR_E2 R
4004
4068
4005
SETPA_ERR
R
4069
4006
OPEPA_ERR
R
4070
RJCERR R
4008
4071
4009
FRAM_ERR
R
4072
4010
4073
ADBO R
4011
CTLPA_ERR
R
4074
ADBO_E1 R
4012
4075
4033
E1_ERR
R
4076
4035
E3_ERR
R
4077
4036
4078
4038
4079
4039
4080
4040
4083
4042
4097
PVBO_L1 R
4043
COM_E3_ERR
R
4098
RSPBO_L1 R
4044
4099
CRSPBO_L1 R
4046
4100
4101
PVPOVER_L1 R
4102
PVMOVER_L1 R
4103
4111
ATERR_L1 R
4112
4113
PVBO_L2 R
4114
RSPBO_L2 R
4115
CRSPBO_L2 R
4116
4117
PVPOVER_L2 R
4118
PVMOVER_L2 R
4119
4127
ATERR_L2 R
4128
