24-12
PPC Manual Revision 1
Chapter 24: I Relays (Coil)
Input (Status) Relay and Output (Status) Relay (5025 to 5280)
I relay No. Symbol Description
5025 to 5040 X_DI1 to X_DI3
5046 X_DI16
Control (Status) Relay (5281 to 5408)
I relay No. Symbol Description
5281 to 5296
AL1_CTL to AL3_
CTL
Internal Relay (5537 to 5792)
I relay No. Symbol Description
5537 to 5664 M01 to M128
You can read/write data from/to the area via communication.
function
5665 to 5696 M01_B to M32_B
You can read/write data from/to the area via communication.
function
5697 to 5792 M33_B to M128_B
You can read/write data from/to the area via communication.
function
DI terminals
NO. I relay symbol R/W
6305
DI1
R
6306
DI2
R
6307
DI3
R
6326
DI16
R
DO terminals
NO. I relay symbol R/W
6433 OUT_AL1 R
6434 OUT_AL2 R
6435 OUT_AL3 R
DI Terminals and DO Terminals (6305 to 6560)
I relay No. Symbol Description
6305 to 6320 DI1 to DI3
6326 DI16
6433 to 6448
OUT_AL1 to OUT_
AL3
