Figure 72: Audio input ports on the XT Series
You define settings for each type of audio device, not per port on the XT Codec Unit. Therefore
there are separate settings for each type of microphone, even when some would share the same
type of connection.
Before you begin
Choose and then connect the analog audio equipment you need as described in
Connecting
Microphones and Speakers to the XT Series on page 59.
If configuring from the endpoint, you must first enable advanced configuration, as described in
Enabling Advanced Maintenance on the XT Series on page 112.
Procedure
1. Access the analog audio settings. From the XT Series web interface, select Administrator
settings > I/O connections > Audio - Input > Analog. From the endpoint's main menu,
select Configure > Advanced > I/O connections > Audio - Input.
2. Select the type of audio input you want to configure.
Figure 73: Choices of audio input to configure
Configuring Microphones
April 2015 Avaya Scopia
®
XT Series Deployment Guide 105
