Avaya Scopia XT5000 Deployment Guide

Depending on the location of the XT Series, a unidirectional port might be inbound to the
organization or outbound from the organization. For example:
• Port 161 is an outbound port from Scopia
®
Management or an SNMP management server to
an external XT Series.
• Port 162 is an inbound port from an external XT Series to Scopia
®
Management or an SNMP
management server.
Important:
On stateful firewalls, ports are left open to response data for an allocated period of time after the
initial request. For unidirectional ports, this response is the only data allowed through in the
opposite direction. On bidirectional ports, data can be initiated and sent through in both
directions.
If you are opening unidirectional ports for the XT Series, see Table 6: Unidirectional ports to open
for the XT Series on page 34. You need to determine if they are inbound or outbound depending
on the source and destination.
If you are opening bidirectional ports for the XT Series, see Table 7: Bidirectional ports to open for
the XT Series on page 39.
Table 6: Unidirectional ports to open for the XT Series
Port
Range
Protocol Source Destination Functionality Result of
Blocking Port
Required
69 TFTP
(TCP)
XT Series TFTP server Enables the XT
Series to send
configuration, log,
and other system
files to a TFTP
server.
The XT Series
cannot send files
to a TFTP server.
Optional
80 HTTP
(TCP)
Web client
(HTTP) /
Scopia
®
Desktop
Client
XT Series Enables you to
remotely manage
the XT Series via
the XT Series web
user interface
using HTTP.
Enables you to
manually activate
Screen Link to
share content
from your
computer to the
XT Series without
having a physical
connection
between the two.
You cannot
access the XT
Series web server
using HTTP.
You cannot
manually activate
Screen or Mobile
Link.
Sonic proximity
detection can still
activate Screen or
Mobile Link
automatically
even if this port is
closed.
Recommended
if accessing the
XT Series
remotely via a
web browser
using HTTP.
Recommended
if using Screen
Link or Mobile
Link.
Table continues…
Planning the Topology of the Avaya Scopia
®
XT Series Deployment
34 Avaya Scopia
®
XT Series Deployment Guide April 2015
Comments? infodev@avaya.com
