Troubleshooting
AVENTICS | Marex 3D | R417003094–BDL–001–AA 105
English
Dev SPow 091/123/155/187 Light xx Retr spring sens
Dev SPow 096/128/160/192 Light xx Retr Sys error
Dev SPow 193 Warning Oil 50 Warning
Dev SPow 195 Light Oil 75 Alarm
Dev SPow 197 Light Oil Low Level
Dev SPow 207 Light PVP Emergency
Dev SPow 208 Light PVP Emergency Ext
Dev SPow 225 Warning Oil 50 Warning 2
Dev SPow 227 Light Oil 75 Alarm 2
Dev SPow 229 Light Oil Low Lever2
Dev SPow 239 Light PVP Emergency 2
Dev SPow 240 Light PVP Emergency Ext 2
Source Device type Error No. Error state Text message
Source Device type Error No. Error state Text message Further information Remedial action
Dev T750 001 Light x. yyy guarding fail The module does not
respond.
Check cabling and
power supply.
Dev T750 033 Light x. yyy new HW
config
The configuration of
the module has
changed.
Repeat
parameterization: Set
ID to 0, restart the
system, then reset the
ID to the inital value.
Dev T750 046 Light x. yyy int. bus error Internal error in the
bus communication
Verify if the module is
complete and all
segments are properly
connected.
Source Device type Error No. Error state Text message Further information Remedial action
Dev NMEA 033 Warning Al 1 value not OK Compass sensor is
defective. Incorrect
messages are
received or none at
all.
Verify the wiring and
installation conditions.
Dev NMEA 034 Warning Al 2 value not OK Rotation rate sensor
is defective. Incorrect
messages are
received or none at
all.
Verify the wiring and
installation conditions.
