2-6 Human-Machine Interface DECS-200
Ref. Parameter Minimum Maximum Increment Default
Off-Line Takeover OEL
Time Delay
0.1 s 20.0 s 0.1 s 0.1 s
6.5 On-Line Takeover OEL
Max Current
0.0 A 30.0 A 0.1 A 0.0 A
On-Line Takeover OEL
Min Current
0.0 A 15.0 A 0.1 A 0.0 A
On-Line Takeover TD 0.1 s 20.0 s 0.1 s 0.1 s
6.6 UEL Curve, Pnt 1 Watts 0 kW 49 kW 1 kW 0 kW
UEL Curve, Pnt 2 Watts 0 kW 49 kW 1 kW 0 kW
UEL Curve, Pnt 3 Watts 0 kW 49 kW 1 kW 0 kW
UEL Curve, Pnt 4 Watts 0 kW 49 kW 1 kW 0 kW
UEL Curve, Pnt 5 Watts 0 kW 49 kW 1 kW 0 kW
6.7 UEL Curve, Pnt 1 Vars 0 kvar 49 kvar 1 kvar 0 kvar
UEL Curve, Pnt 2 Vars 0 kvar 49 kvar 1 kvar 0 kvar
UEL Curve, Pnt 3 Vars 0 kvar 49 kvar 1 kvar 0 kvar
UEL Curve, Pnt 4 Vars 0 kvar 49 kvar 1 kvar 0 kvar
UEL Curve, Pnt 5 Vars 0 kvar 49 kvar 1 kvar 0 kvar
6.8 SCL High Limit 0.0 A 66,000.0 A 1.0 A 0.0 A
SCL High Limit Time 0.0 s 60.0 s 1.0 s 0 s
SCL Low Limit 0.0 A 66,000.0 A 1.0 A 0 A
7.1.1 Gen. Rated Output V 85 V 30,000 V 1 V 120 V
Gen. Rated Output I 10.0 A 60,000 A 0.1 A 200.0 A
Gen. Rated Frequency 50 Hz 60 Hz 10 Hz 60 Hz
7.2.1 Rated Field Voltage 1.0 V 180.0 V 0.1 V 32.0 V
Rated Field Current 0.1 A 15.0 A 0.1 A 5.0 A
Pole Ratio 0 10 0.01 0
7.3.1 Gen. Sensing PT Pri. 1 V 30,000 V 1 V 120 V
Gen. Sensing PT Sec. 1 V 600 V 1 V 120 V
Bus Sensing PT Pri. 1 V 500,000 V 1 V 120 V
Bus Sensing PT Sec. 1 V 600 V 1 V 120 V
Gen. CT Pri. 1 A 60,000 A 1 A 200 A
Gen. CT Sec. 1 A 5 A 4 A 5 A
7.4.1 Sensing Configuration 1-phase A-C, 3-phase N/A 1-ph A-C
Auxiliary Input Type Voltage, Current N/A voltage
Cross Current Gain –30.00 30 0.01 0
7.4.2 AVR Mode Aux. Gain –99.00 99 0.01 1
FCR Mode Aux. Gain –99.00 99 0.01 1
Var Mode Aux. Gain –99.00 99 0.01 1
PF Mode Aux. Gain –99.00 99 0.01 1
Inner or Outer Loop Inner, Outer N/A Inner
7.5.1 Relay 1 Contact Sense NC, NO N/A NO
Relay 1 Annunc. Type Momentary, Maintained, Latched N/A Maintained
Relay 1 Moment Time 0.10 s 5.00 s 50 ms 0.10 s
Field Overvoltage On, Off N/A Off
Field Overcurrent On, Off N/A Off
Stator Undervoltage On, Off N/A Off
7.5.2 Stator Overvoltage On, Off N/A Off
Underfrequency On, Off N/A Off
Overexcitation Limit On, Off N/A Off
Underexcitation Limit On, Off N/A Off
FCR Mode On, Off N/A Off
