THEORY OF OPERATION Chapter 2
2 - 23
CAUTION
To prevent corruption of the configuration data, do not turn off the
pump or press any key while UPDATING is being displayed.
2.3.3.3 Configuration Groups
The pump supports eight configuration groups including:
1. LIBRARY Group
2. MODES Group
3. SYRINGES Group
4. DEFAULTS Group
5. MISC (Miscellaneous) Group
6. ALERTS Group
7. CLOCK Group
8. IDENT (Identifier) Group
All groups may be selected for edit or review. In the “Configuration Set” mode, the pump’s
configuration may be modified by enabling or disabling any option offered within each
group. In the “Configuration Review” mode, the pump’s configuration cannot be modified
and group options may be reviewed but not altered.
2.3.3.3.1 LIBRARY Group
The LIBRARY configuration group allows the operator to perform pump-to-pump
configuration replication; to create, modify or delete protocol libraries; or to create, modify
or delete protocols.
2.3.3.3.2 MODES Group
The MODES configuration group allows the operator to individually enable and disable any
of the following 18 infusion modes:
1. ML/MIN 6. UNITS/HR 11. MCG/HR 16. MG/KG/MIN
2. ML/HR 7. SINGLE DOSE 12. MG/MIN 17. MG/KG/HR
3. MUNITS/MIN 8. MANUAL SCHEDULE 13. MG/HR 18. CUSTOM DILUTION
4. MUNITS/HR 9. AUTO SCHEDULE 14. MCG/KG/MIN
5. UNITS/MIN 10. MCG/MIN 15. MCG/KG/HR
