baxter Auto Syringe AS50 Service Manual

ROUTINE MAINTENANCE Chapter 5
5 - 11
• (*D*) If the inches number is not within specification, restart calibration from step
5.3.5.4 and record the “2nd Reading” inches value and “Pass” or “Fail” on the
data sheet.
16. Remove the fixture from the pump and install the CAS4005801 fixture.
17. (*D*) Repeat the process detailed in step 13 and record the inches number on the
data sheet. Verify that the inches number is between -0.03 to +0.02 inches (-0.03 <
inches value < +0.02).
• (*D*) If the inches number is within specification, check “Pass” and record N/A
next to “2nd Reading” on the data sheet. Proceed to step 18.
• (*D*) If the inches number is not within specification, replace the barrel clamp,
restart calibration from step 5.3.5.4 and record the “2nd Reading” inches value
and “Pass” or “Fail” on the data sheet.
18. Remove the fixture from the pump and install the CAS4006801 fixture.
19. (*D*) Repeat the process detailed in step 13 and record the inches number on the
data sheet. Verify that the inches number is between 0.995 to 1.035 inches (0.995 <
inches value < 1.035).
• (*D*) If the inches number is within specification, check “Pass” and record N/A
next to “2nd Reading” on the data sheet. Proceed to step 20.
• (*D*) If the inches number is not within specification, replace the barrel clamp,
restart calibration from step 5.3.5.4 and record the “2nd Reading” inches value
and “Pass” or “Fail” on the data sheet.
20. Remove the fixture from the pump.
21. Press CONFIRM. An UPDATING message appears on the display for a few seconds
while the new calibration information is being saved. When this message disappears,
the new syringe recognition calibration settings become stored and a new message,
PRESSENS, appears on the display.
CAUTION
To prevent corruption of the calibration data, do not turn off the pump
while UPDATING is being displayed.
