Chapter 5 ROUTINE MAINTENANCE
5 - 10
8. Observe that CLAMP 0.291 appears on the display. Disregard the A/D count number
appearing in Field 3 of the display.
9. Open the barrel clamp and remove the fixture.
10. Set the CAS4004801 fixture onto the barrel clamp cradle and repeat steps 6 and 7.
11. Observe that, from top to bottom, the display now indicates the following:
SYRNGREC
NOTE
DO NOT PRESS CONFIRM.
12. Remove the fixture from the pump and reinstall the CAS4003801 fixture.
13. (*D*) Verify the barrel clamp calibration by repeating steps 6 and 7, except instead of
listening for the “beep,” stop IMMEDIATELY when the LOCK LED illuminates and
record the inches number being displayed as the “1st Reading” on the data sheet.
Verify that the inches number is between 0.7367 to 0.7467 inches (0.7367 < inches
value < 0.7467).
• (*D*) If the inches number is within specification, check “Pass” and record N/A
next to “2nd Reading” on the data sheet. Proceed to step 14.
• (*D*) If the inches number is not within specification, restart calibration from step
5.3.5.4 and record the “2nd Reading” inches value and “Pass” or “Fail” on the
data sheet.
NOTE
DO NOT PRESS CONFIRM.
14. Remove the fixture from the pump and install the CAS4004801 fixture.
15. (*D*) Repeat the process detailed in step 13 and record the inches number on the
data sheet. Verify that the inches number is between 0.2859 to 0.2959 inches (0.2859
< inches value < 0.2959).
• (*D*) If the inches number is within specification, check “Pass” and record N/A
next to “2nd Reading” on the data sheet. Proceed to step 16.
A/D count number
Inches number
