Accessories
96 Hillrom Progressa ICU Hospital Bed Instructions for Use (171528 REV 15)
If the P7511A IV pole is not installed, there is an adapter bushing installed to allow use of a removable IV
pole.
To Stow
Pull up on the IV pole, and fold it down toward the center of the bed.
To Use
Pull up on the IV pole from the stowed position so that it is in the vertical position. The IV pole will
then move down to lock in the vertical position.
VERTICAL OXYGEN TANK HOLDER
Warning—Each vertical oxygen tank holder safe working load is 30 lb (13.6 kg). Exceeding the safe
working load can cause injury or equipment damage.
KINETEC OXYGEN TANK HOLDER
The Kinetec oxygen tank holder is a removable tank holder that can be installed at the head end of the
bed, in the left or right IV pole sockets. The oxygen tank holder accommodates cylinder type B5 with a
regulator.
The oxygen tank holders are located in the head end corners of
the upper frame. The blue sleeve holds a steel tank and the gray
sleeve holds an aluminum tank. Each oxygen tank holder
accommodates one D-size or E-size oxygen tank with a regulator.
To Install
Install the oxygen tank in the holder. Depending on the date of
manufacture, the holder will have either a rigid plastic bottom or a
spring-loaded metal support cage.
If the holder has a spring-loaded metal support cage, make sure that
the support cage completely lowers when you install the tank.
To Remove
Lift the tank out of the holder.
A blue insert sleeve is required for steel oxygen tanks. A gray insert
sleeve is required for aluminum oxygen tanks.
