Graphical Caregiver Interface (GCI) Controls
Hillrom Progressa ICU Hospital Bed Instructions for Use (171528 REV 15) 27
Lock the GCI Screen
At any time the user can hide screen information by pressing the lock symbol in the lower left hand
corner of the screen. The unlock screen will show until the screen is active.
HOME SCREEN DESCRIPTION
.
Not all indicators and controls are available on all beds.
• Slide your finger across the screen at the location
shown.
The screen will dim after 1 minute of not being touched.
After 2 minutes of the screen not being touched the
screen will lock. When locked, the screen information will
still be visible but if the screen is touched the user will
need to unlock it again.
Item Description Item Description
Information Indicators—tap the indicators for
status details.
Menu Controls—use the scroll arrows or slide
your finger up and down on the menu bar to see
the different menu options.
A Bed Exit status M Home
B Bed Zeroed status N Alerts
C Surface status O Scale
D Alternating low pressure (ALP) ON P Surface
E Normal (Continuous low pressure (CLP)) Q Pulmonary Therapies
F Trendelenburg status R Reminders
G Rotation status S Settings/Preferences
H Percussion and Vibration status
I Bed not in the lowest position
