Alerts and Information Indicators
12 Hillrom Progressa ICU Hospital Bed Instructions for Use (171528 REV 15)
While on battery power, the bed will operate as follows:
• All bed articulations will operate
• Integrated surfaces will remain inflated, but will not adjust pressures
• The GCI screen will not display
SERVICE REQUIRED
HIP POSITION LOCATOR
LINE-OF-SITE HEAD ANGLE INDICATOR
The Service required indicator illuminates when the bed detects a
malfunction. Contact the facility-authorized maintenance
department for assistance.
A hip position label appears on the intermediate siderails to indicate the
correct position of the patient's hips while on the bed. The labels are on
the top of the intermediate siderail just above the caregiver controls.
Proper placement of the patient increases the effectiveness of the
SlideGuard Patient Position Mechanism and StayInPlace Patient Position
Mechanism. These minimize migration of the patient to the foot end of the
bed when you raise the head section.
The head angle indicators mechanically indicate the approximate angle of
the head section from -15° to +80° with respect to the floor. The head
siderails contain head angle indicators on their outboard sides. The degree
where the indicator ball rests is the correct angle. The angle indication is
also shown on the home screen on the GCI screen.
