Caregiver Siderail Controls
Hillrom Progressa ICU Hospital Bed Instructions for Use (171528 REV 15) 23
BED FLAT CONTROL
Bed Flat controls are provided so that a caregiver can easily return the patient deck to the level position
from any articulated position.
3. The individual sections move to the flat position. If the bed is starting in the Chair position, then it
will move through the Reclining position on the way to level.
4. When all sections are flat, the bed stops and one beep sounds.
SIDECOM COMMUNICATION SYSTEM
Warning—Failure to connect the SideCom Communication System cable may result in delay of critical
care to the patient.
NURSE CALL
The patient can use the Nurse Call control to call the nurse when the control is lit.
When a Nurse Call control is activated, a signal is sent to the nurse’s station. Voice communication is
provided through a speaker/microphone that is on the inside of both head siderails. See “Sidecom
Communication System” on page 23.
• When the nurse station communication line is open, the indicator turns green. The nurses station is
ready for you to speak.
• Speak into the speaker/microphone located on the inboard side of the head-end siderails.
To Activate
1. Press and hold the Bed Flat control.
2. The intermediate frame returns to level from the tilted position.
The SideCom Communication System option provides a control for Nurse Call and
other entertainment features.
The SideCom Communication System connector is at the head end of the bed
below the head board.
To Activate
Press a Nurse Call control. These will occur:
• The amber indicator near the Nurse Call control will come on and single beep will
sound to let you know that the call has been sent.
