Bed Frame Features
Hillrom Progressa ICU Hospital Bed Instructions for Use (171528 REV 15) 71
PERMANENT IV POLE OPTION
Warning—Keep hands away from the connection between the sliding parts when raising and lowering
the movable portion of the IV pole or injury could occur.
To help prevent equipment damage, obey these cautions:
• Caution—Permanent IV Pole safe working load is 40 lb (18.1 kg); do not exceed the safe
working load.
• Caution—Do not mount infusion pumps on the lower section of an IV pole. Interference with
head section articulation could result.
To Raise
1. Lift the IV pole from its stored position from behind the headboard.
2. Make sure that the pole drops and locks into position.
3. Hold the bottom section.
4. Raise the middle and upper sections of the pole until they click and lock into place. The pole is ready
for use.
To Store
The Permanent IV Pole option consists of one IV pole that supports up to
two IV pumps plus bags. The IV pole is attached to the frame near one of
the corners of the headboard.
Up to 40 lb (18.1 kg) of total weight can be supported per pole.
A permanent IV pole will use one of the removable IV pole sockets on the
head-end of the bed.
1. Grasp and hold the upper section of the pole. Pull the knob
out and lower the upper pole section.
2. Lift the lower section of the pole up and rotate the pole down
to the stored position between the transport handles and the
headboard. The poles should rest in the storage slots provided
on the frame.
