Accessories
100 Hillrom Progressa ICU Hospital Bed Instructions for Use (171528 REV 15)
(Warnings continued) Obey all warnings throughout the manual. Failure to do so could cause injury
and or equipment damage:
• Warning—Make sure to remove the ICU prone head positioner’s detachable ball joint lock
handle from the ball joint after it is locked and the patient is in the prone position.
• Warning—Do not store equipment below the head adapter bracket when the proning
accessory is in use.
• Warning—Adjust the patient, if necessary, after any surface transition or bed articulation to
make sure the head is correctly aligned on the foam face cushion/head support of the proning
accessory.
• Warning—Make sure to monitor and adjust the patient at regular intervals.
• Warning—Make sure to adjust the patient when the integrated air surface transitions from
max-inflate to normal mode.
• Warning—Stay clear of pinch points when you adjust the Allen ICU prone head positioner that
the mirror.
For technical support of the proning accessory, contact Hillrom Allen Medical (800) 433-5774.
To Install
1. Put the bed in the flat position.
2. Remove the headboard.
3. Lower the transport handles and IV pole.
4. If applicable, remove any equipment from the fracture frame
sockets.
5. Lockout the head and knee articulation controls.
6. If applicable, remove the plastic inserts from the traction
equipment sockets on the head-end of the bed.
7. On the left side of the head adapter bracket, push the snap
button to install the head adapter bracket in the traction
equipment sockets. Make sure the bracket is fully inserted
into the socket.
If applicable, the push handles and IV pole will be in the stowed
position and will be under the bracket.
