pro+ Surface Instruction for Use (209196 REV 8) 27
CENTRELLA Smart+ Bed
27. Use the alcohol-based cleaner to clean the metal plate (B). Let the
plate dry.
28. Remove the adhesive covering from the status indicator label (D).
29. Make sure the label (D) is in the correct orientation, then install the
label on to the metal plate (B). Firmly press the label into position for
10 seconds.
30. Go to “Step 4: Final Steps” on page 28.
Step 3B: Install the MCM Status Indicator Mounting Kit
(Rental Only)
The mount for the MCM status indicator
is to be installed on the outside of the
footboard. The rental MCM indicator
strap can be put on the right or left side
of the footboard.
31. Lift the foot end of the surface.
32. Align the holes of the foot end flap with the footboard sockets in the
bed (see below).
33. Align the footboard posts to go through the holes on the flap, and
install the footboard.
Make sure that the status indicator cord is not between the installed
footboard and bed.
