72 pro+ Surface Instruction for Use (209196 REV 8)
900 Beds
15. Route the power cord between the
lower frame and headboard
support.
Step 3: Install the MCM Status Indicator Mounting Kit
The mount for the MCM status indicator
(status indicator) is to be installed on the
outside of the footboard on either the
bottom-left or bottom-right.
16. Install the footboard.
Make sure that the status indicator cable is not between the
footboard and bed.
17. Make sure the status indicator can reach the mount location before
you start to install the mount assembly.
Warning—Alcohol-based cleaners are flammable and toxic to skin,
eyes, and respiratory tract. Do not use near an open flame. Do not
use in confined areas. Injury could occur.
18. On the outside of the footboard, use the alcohol-based cleaner to
clean the area where the status indicator is to be installed (this
includes new footboards). Let the area dry.
