Step 3: Install the MCM Status Indicator Mounting Kit
The mount for the MCM status indicator
(status indicator) is to be installed on the
outside of the footboard on either the
bottom-left or bottom-right.
16. Install the footboard.
NOTE:
Make sure that the status indicator cord is not between the installed
footboard and bed.
17. Make sure the status indicator can reach the mount location before
you start to install the mount assembly
WARNING:
Warning—Alcohol-based cleaners are flammable and toxic to skin,
eyes, and respiratory tract. Do not use near an open flame. Do not
use in confined areas. Injury could occur.
18. On the outside of the footboard, use the alcohol-based cleaner to
clean the area where the status indicator is to be installed (this
includes new footboards). Let the area dry.
19. Remove the adhesive covering (A)
from the metal plate (B) of the
mount assembly, and firmly press
the metal plate (B) into position for
10 seconds.
20. Install the screw (C) to attach the metal plate to the footboard.
NOTE:
Installing the screw on to the footboard will not void the warranty of
the product.
